| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | SPRING | S. S. 304 |
| 3 | BOARD | BRASS |
| 4 | WASHER | NBR |
| 5 | CAP | BRASS |
WELCOME TO VENUS VALVES INDUSTRIES
-
Follow Us :
-
WELCOME TO VENUS VALVES INDUSTRIES
| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | SPRING | S. S. 304 |
| 3 | BOARD | BRASS |
| 4 | WASHER | NBR |
| 5 | CAP | BRASS |
| Size Inch | Working Bar | Pressure Psi | Max. Working Temperature |
|---|---|---|---|
| 1/2'' | 16 | 232 | -20° to 100° |
| 3/4'' | 16 | 232 | -20° to 100° |
| 1 | 16 | 232 | -20° to 100° |
| 1.1/4 | 16 | 232 | -20° to 100° |
| 1.1/2 | 16 | 232 | -20° to 100° |
| 2 | 16 | 232 | -20° to 100° |
| 2.1/2 | 16 | 232 | -20° to 100° |
| 3 | 16 | 232 | -20° to 100° |
| 4 | 16 | 232 | -20° to 100° |
| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
|---|---|---|---|---|---|---|---|---|---|
| A | 33.5 | 41.5 | 48 | 60 | 69 | 81 | 104 | 120 | 150 |
| B | 51.5 | 59 | 66.5 | 78 | 89.5 | 102 | 119 | 130 | 148.5 |
