| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | CAP | BRASS |
| 3 | DISK | BRASS |
| 4 | WASHER | NBR |
| 5 | GASKET | ASBESTOS |
WELCOME TO VENUS VALVES INDUSTRIES
-
Follow Us :
-
WELCOME TO VENUS VALVES INDUSTRIES
| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | CAP | BRASS |
| 3 | DISK | BRASS |
| 4 | WASHER | NBR |
| 5 | GASKET | ASBESTOS |
| Size Inch | Working Bar | Pressure Psi | Max. Working Temperature |
|---|---|---|---|
| 1/2'' | 13.8 | 200 | -20° to 150° |
| 3/4'' | 13.8 | 200 | -20° to 150° |
| 1 | 13.8 | 200 | -20° to 150° |
| 1.1/4 | 13.8 | 200 | -20° to 150° |
| 1.1/2 | 13.8 | 200 | -20° to 150° |
| 2 | 13.8 | 200 | -20° to 150° |
| 2.1/2 | 13.8 | 200 | -20° to 150° |
| 3 | 13.8 | 200 | -20° to 150° |
| 4 | 13.8 | 200 | -20° to 150° |
| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
|---|---|---|---|---|---|---|---|---|---|
| A | 45 | 56 | 66 | 75 | 85 | 104 | 112 | 136 | 175 |
| B | 50 | 55 | 64.5 | 76 | 84.5 | 100 | 124 | 140 | 181 |
