| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
|---|---|---|---|---|---|---|---|---|---|
| A | 58 | 67 | 76 | 93 | 103 | 119 | 133 | 150 | 171 |
| B | 38 | 41 | 50 | 60 | 68 | 79.5 | 102 | 116 | 145 |
WELCOME TO VENUS VALVES INDUSTRIES
-
Follow Us :
-
WELCOME TO VENUS VALVES INDUSTRIES
| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
|---|---|---|---|---|---|---|---|---|---|
| A | 58 | 67 | 76 | 93 | 103 | 119 | 133 | 150 | 171 |
| B | 38 | 41 | 50 | 60 | 68 | 79.5 | 102 | 116 | 145 |
| Size Inch | Working Bar | Pressure Psi | Max. Working Temperature |
|---|---|---|---|
| 1/2" | 16 | 232 | -20° to 120° |
| 3/4" | 16 | 232 | -20° to 120° |
| 1" | 16 | 232 | -20° to 120° |
| 1.1/4" | 16 | 232 | -20° to 120° |
| 1.1/2" | 16 | 232 | -20° to 120° |
| 2" | 16 | 232 | -20° to 120° |
| 3" | 16 | 232 | -20° to 120° |
| 4" | 16 | 232 | -20° to 120° |
| No | Part | Material |
|---|---|---|
| 1 | BODY | BRASS |
| 2 | NET | BRASS |
| 3 | BOARD | BRASS |
| 4 | WASHER | NBR |
