| No | Part | Material |
|---|---|---|
| 1 | BODY | FORGED BRASS |
| 2 | GATE | FORGED BRASS |
| 3 | STEM | BRASS |
| 4 | GASKET | ASBESTOS |
| 5 | LOCKING NUT | BRASS |
| 6 | UPPER BODY | BRASS |
| 7 | STEM SEAT | PTFE |
| 8 | RING | BRASS |
| 9 | NUT | BRASS |
| 10 | WHEEL | MILD STEEL |
| 11 | NAME PLATE | ALUMINIUM |
| 12 | NUT | MILD STEEL |
| Size Inch | Working Bar | Pressure Psi | Max. Working Temperature |
|---|---|---|---|
| 1/2" | 20 | 290 | -20° to 120° |
| 3/4" | 20 | 290 | -20° to 120° |
| 1" | 20 | 290 | -20° to 120° |
| 1.1/4" | 20 | 290 | -20° to 120° |
| 1.1/2" | 20 | 290 | -20° to 120° |
| 2" | 20 | 290 | -20° to 120° |
| 2.1/2" | 20 | 290 | -20° to 120° |
| 3" | 20 | 290 | -20° to 120° |
| 4" | 20 | 290 | -20° to 120° |
| Size | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
|---|---|---|---|---|---|---|---|---|---|
| A | 42 | 47 | 53 | 59 | 64 | 72 | 83 | 92 | 102 |
| B | 87 | 103 | 115 | 136 | 149 | 171 | 217 | 251 | 309 |
| C | 54 | 62 | 62 | 73 | 79 | 86 | 99 | 108 | 151 |
